Introduction¶

An agent service for monitoring system usage, board information and internal sensor data (such as cpu usage, fan speed from HEROSDK), connecting those data to HEROSpace in linux based operating system. The system data is reorganized in json format and HEROAgent is communicate with HEROSpace based on MQTT protocol. With this agent, user can easily monitoring device hw and system status on network anytime, anywhere.

Architecture¶

HEROAgent includes two parts. One is the main part for collecting basic board data, data uploading and service control. The Sencond part is plugin configuration for other uploading protocol and external sensor data collection.

Main Application:
1. Data collecting : getting board hardware information from cli tool based on HEROSDK (voltage, cpu temperature, … ) and system usage
2. Configuration : data updating frequency
3. System manager : system controlled by linux systemd
4. Data uploading : default using MQTT protocol
5. Device registering : board needs to register to server first for device management on server
6. Plugin : addictional data uploading protocol and external sensor data collecting
Plugins:
1. Additional data uploading protocol.
2. Additional external sensor data.

Plugin	Description
HTTP	Data uploading thourgh HTTP
AMQP	Data uploading thourgh AMQP protocol
RS232/RS485	Collecting external sensor data through RS232/RS485
Modbus	Collecting external sensor data throught modbus protocol
InfluxDB	Collction external data from database
MongoDB	Collction external data from database

Requirement¶

Hardware Requirement:
1. 9th Generation Intel Core, Pentium Gold, Celeron, and Xeon formerly Coffee Lake
2. 8th Generation Intel Core, Pentium Gold, and Celeron formerly Whiskey Lake
3. Intel Pentium Silver and Celeron formerly Gemini Lake
Software Requirement:
1. MQTT: mosquitto package
2. JSON: jq package

OS Support list¶

Ubuntu, Debian, Fedora, CentOS, OpenSUSE

How to install¶

Please follow below steps to install HEROAgent(Sample):

Download HEROAgent_lite_v1.0.0.zip from here
Unzip package:

$ unzip HEROAgent_lite_v1.0.0.zip
$ cd HEROAgent_lite_v1.0.0/

Run install.sh for installing HEROAgent(Sample):

$ sudo ./install.sh

Check if HEROAgent(Sample) installed successfully:

$ systemctl status heroagent_lite
● heroagent_lite.service - Run agent to report hw monitor
    Loaded: loaded (/etc/systemd/system/heroagent_lite.service; enabled; vendor preset: enabled)
    Active: active (running) since Tue 2019-11-19 16:24:30 CST; 2min 20s ago
  Main PID: 25896 (heroagent_lite)
     Tasks: 3 (limit: 4915)
    CGroup: /system.slice/heroagent_lite.service
            ├─11508 /bin/bash /usr/bin/heroagent_lite
            ├─11510 herosuit --sensor
            ├─11728 /bin/bash /usr/bin/heroagent_lite
            └─25896 /bin/bash /usr/bin/heroagent_lite

Using below command to listen data sent from HEROAgent(Sample):

$ mosquitto_sub -t "hmi/#"
output:
{"hwm":[{"ext":0,"name":"Cpu0","type":7,"value":20},{"ext":0,"name":"Cpu1","type":7,"value":0},{"ext":0,"name":"Cpu2","type":7,"value":0},{"ext":0,"name":"Cpu3","type":7,"value":20},{"ext":0,"name":"Cpu4","type":7,"value":16.67},{"ext":0,"name":"Cpu5","type":7,"value":33.33},{"ext":0,"name":"Cpu6","type":7,"value":20},{"ext":0,"name":"Cpu7","type":7,"value":0},{"ext":0,"name":"memory","type":8,"value":38.73},{"ext":0,"name":"/","type":10,"value":92},{"ext":0,"name":"/boot/efi","type":10,"value":1},{"ext":0,"name":"CPU Temp","type":1,"value":0},{"ext":0,"name":"SYS Temp","type":1,"value":0},{"ext":0,"name":"3.3V","type":2,"value":0},{"ext":0,"name":"VBat","type":2,"value":0},{"ext":0,"name":"5V","type":2,"value":0},{"ext":0,"name":"12V","type":2,"value":0},{"ext":0,"name":"Vcore","type":2,"value":0},{"ext":0,"name":"Vmem","type":2,"value":0},{"ext":0,"name":"CPU Fan Speed","type":3,"value":0},{"ext":0,"name":"SYS Fan Speed","type":3,"value":0},{"ext":0,"name":"brightness 1","type":4,"value":-1}],"ts":1574144316110,"uuid":"11111111-2222-3333-4444-555555555555","ver":"2.1.0"}
...
